The Tiltable Downlight Range is a comprehensive collection of extremely discreet, low glare LED fittings.
There are five sizes / power models, which come in three circular trim options.
With power options ranging from 7W to 25W, these lights are ideal for ceiling heights from 2m to 8m, making them suitable for commercial, residential and retail applications.
Available in a wide variety of beam angles and colour temperatures and available in DALI and Self Dim models.
Narrow model is Available in: 10°. The render above illustrates the effect of all beam angles in Comfort Glow Tilt Range.
Full Specification Sheet
Photometric Files
61021 [Trim] 1 – [Power] – [Dimming] – [LED Colour Code] – [Beam Angle] – [Finish Code]
61021 0 1 – 008 – 08 – 927 – 15 – 2
Tiltable Narrow Downlight with 82mm Standard Circular Trim, 8W / 180mA Driver, 90+CRI 2700K LED, 10° Optic, Trim Black Finish.
Principle variants, see Specification Sheets for full details.
| ARTICLE NUMBER | DESCRIPTION |
|---|---|
| 6102101 | Tiltable Downlight with 110mm Circular Standard Trim |
| 6102111 | Tiltable Downlight with 110mm Circular Trimless Trim |
| Power | 20W [020], 28W [028] |
| Dimming | Non Dim [01], Traic [02], 0/1-10V [03], DALI [04], Casambi [08], Silvair [09] |
| LED Colour Codes | 2700K [927], 3000K [930], 3500K [935], 4000K [940] |
| Optic Codes | 15° Narrow [15], 24° Medium [24], 36° Wide [36], 60° Extra Wide [60] |
| Finish Codes (Painted) | White RAL9016 [1], Black RAL 9011 [2] |
